Die-Casting Alloy Smart Lamp Post

1. The lamp post is made of Q235 steel with a thickness of δ=4mm or more. The suppliers are well-known steel mills such as Baosteel and Magang.
2. The lamp post and bracket are hot-dip galvanized both inside and outside, with a galvanized layer thickness of not less than 85μm. The anti-corrosion lifespan is more than 30 years. The surface is treated with DuPont metal paint or spray, with a thickness of not less than 100μm. The number of modified parts due to straightening or other factors should not exceed 2, and the area for modification should not exceed 5% of the pole surface area.
3. The steel pole should be well welded. For tapered poles with a length of 8 meters or less, there should be no transverse welds, and the longitudinal welds should be symmetrical and without incomplete penetration. Under the condition of horizontal placement and no load, the straightness deviation of the pole body should be less than 3‰.
4. For flange-type lamp posts, the allowable deviation in pole length is ±0.5% of the pole length, the allowable deviation in cross-sectional dimensions of the pole body is ±0.5%, the allowable deviation in wiring hand hole size is ±5mm, the allowable deviation in the tilt angle of one-piece cantilever lamp poles is ±1°, and after the lamp arm (bracket) is connected and fixed to the lamp post, the deviation between the center verticality and the verticality of the lamp post should not exceed 3°.
5. The inspection door frame of the lamp post should have reinforcement measures to ensure that its mechanical strength is not lower than the strength when the door is closed.
6. The upper end of the inspection door of the lamp post is equipped with an anti-theft triangular stainless steel screw with a diameter of Φ10mm, and the lower end is hinged. The inner wall of the inspection door of the lamp post is welded with PE protection wire terminal.
7. The fastening screws and nuts of the lamp post and bracket are made of stainless steel.
8. The cable junction box is installed inside the bottom lamp holder crossbar, equipped with RT-14 fuse, 250W equipped with 6A fuse, 150W equipped with 4A fuse, 400W equipped with 10A fuse. The junction box is made of PTFE material.
9. The welding reinforcement ribs are required at the connection between the lamp post and the flange, with a thickness of not less than 8mm and a minimum of 4 reinforcement ribs.
10. The overhead line of the lamp post should use aviation waxed line with a rated voltage of not less than 500V. The minimum allowable cross-sectional area of the line core for power less than 400W should be 1.5mm², and the minimum allowable cross-sectional area of the line core for power from 400W to 1000W should be 2.5mm².
11. The overall wind resistance of the lamp post is above 30 m/s, and the seismic grade is above 8.
12. The lamp model drawing is for reference only. The specific dimensions, colors, processes, etc. should be based on actual survey or owner’s requirements.

Why choose us?

• Our years of experience in the industry have made us a leading manufacturer and supplier of Smart Lamp Post products.
• We always pursue the company development scale and efficiency, as well as the sustainable development of enterprises.
• We have a dedicated research and development team that is focused on creating innovative Smart Lamp Post products that meet the ever-changing needs of our customers.
• Well known trademark condenses a lot of wisdom and labor of commodity producers, operators and service providers, and becomes the core weapon for enterprises to win the competition.
• We believe that our commitment to high-quality manufacturing and service sets us apart from other Smart Lamp Post suppliers.
• Manufacture high quality Die-Casting Alloy Smart Lamp Post to meet customer's demand is our final target. We offer competitive solutions without compromising on quality.
• We offer customized Smart Lamp Post products to meet the specific needs of our customers.
• We always take it as our responsibility to enrich our employees, achieve our customers and return to the society.
• Our Smart Lamp Post products are backed by a comprehensive warranty to give our customers peace of mind.
• Creating achievements for our customers and making more contributions to society is the source of motivation for the long-term development of our company, moreover, it is our responsibility and mission.

Our Die-Casting Alloy Smart Lamp Post is an innovative and sophisticated product that is designed to enhance streetlighting solutions across the world. This unique lamp post is manufactured from high-quality die-casting alloy, which is highly durable and corrosion-resistant, making it ideal for outdoor use. Its durable construction also ensures that it can withstand extreme weather conditions, making it a reliable and long-lasting solution to your outdoor lighting needs.

Smart Technology

One of the standout features of our Die-Casting Alloy Smart Lamp Post is its smart technology. This innovative lamp post comes equipped with advanced sensors and controls, which enable it to automatically adjust its brightness levels based on the ambient light conditions. This means that it can provide optimal lighting levels throughout the day and night, thereby ensuring maximum energy efficiency and cost-effectiveness.

In addition, the smart technology incorporated into this lamp post also allows for remote monitoring and control. This means that you can easily access and control your lighting system remotely, from anywhere in the world. This is a great feature for those looking to manage and optimize their energy usage, as well as those who need to quickly respond to lighting emergencies.

Energy Efficiency

When it comes to outdoor lighting solutions, energy efficiency is a top priority for many merchants. Our Die-Casting Alloy Smart Lamp Post is designed with this in mind. The lamp post features an ultra-low power consumption LED light source, which is both efficient and durable, ensuring longevity whilst reducing your operational costs. This means that you can enjoy maximum energy efficiency and cost-effectiveness without sacrificing on the quality of the lighting solutions.

Environmental Responsibility

We recognize that we all have a responsibility to protect the environment, and we are committed to doing our part by designing and manufacturing products that reduce harmful emissions and contribute to a sustainable environment. By using our Die-Casting Alloy Smart Lamp Post, you can help reduce your carbon footprint by reducing energy consumption and eliminating harmful emissions.

Design and Construction

Our Die-Casting Alloy Smart Lamp Post features a modern and sleek design that seamlessly integrates with any architectural style. The lamp post is manufactured using high-quality die-casting alloy, which is highly durable and corrosion-resistant. This ensures that the lamp post retains its aesthetic appeal and functionality for an extended period. The lamp post is also easy to install, with a simple and straightforward process that will save you time and money.

Versatility

Our Die-Casting Alloy Smart Lamp Post is a versatile lighting solution that can be used in a wide range of applications. Whether you need to light up a street, parking lot, or pathway, this lamp post is up to the task. This makes it an ideal solution for merchants looking to offer high-quality lighting solutions across a range of different applications.

Conclusion

Our Die-Casting Alloy Smart Lamp Post is a reliable, versatile, and innovative lighting solution that is designed to meet the needs of merchants across the globe. Whether you need to light up a residential area, commercial space, or industrial zone, this cutting-edge product is the perfect solution. With its advanced technology, energy efficiency, and durability, this lamp post is sure to exceed your expectations and help you create sustainable and reliable outdoor lighting solutions. Choose our Die-Casting Alloy Smart Lamp Post and join the growing number of merchants who are moving towards more sustainable and efficient lighting solutions.
