Galvanized Steel Light Pole

1. The material of the lamp pole is Q235 steel, with a wall thickness of δ ≥ 4mm. The suppliers are well-known steel mills such as Baosteel and Magang.
2. The lamp pole and lamp bracket are hot-dip galvanized inside and outside, with a galvanized layer thickness of not less than 85μm. The anti-corrosion lifespan is over 30 years. The surface is treated with DuPont metal paint or spray coating, with a thickness of not less than 100μm. Modification areas should not exceed 2 locations and should not exceed 5% of the pole surface area.
3. The steel pole should be well-welded. Conical poles with a length of 8 meters or below should have no transverse welds, and the longitudinal welds should be symmetrical without incomplete welding. When horizontally placed without load, the straightness error of the pole should be less than 3‰.
4. For flange-type lamp poles, the allowable length deviation is ±0.5% of the pole length, the allowable cross-sectional dimension deviation is ±0.5%, the deviation in size of the wiring handhole is allowed to be ±5mm, and for once-formed cantilever lamp poles, the allowable deviation in inclination angle is ±1°. After the lamp arm (bracket) is connected and fixed to the lamp pole, the deviation between the center verticality and the pole verticality should not exceed 3°.
5. The inspection door frame of the lamp pole should have reinforcement measures to ensure its mechanical strength is not lower than that of a pole without the door frame.
6. The upper end of the inspection door of the lamp pole is equipped with a theft-proof triangle made of φ10mm stainless steel screws, and the lower end is hinged. PE protective wire terminal connectors are welded on the inner wall of the inspection door of the lamp pole.
7. The fastening screws and nuts of the lamp pole and lamp bracket are made of stainless steel.
8. The cable junction box is installed inside the bottom lamp holder crossbar and equipped with an RT-14 fuse. A 6A fuse is used for 250W, a 4A fuse is used for 150W, and a 10A fuse is used for 400W. The junction box is made of PTFE material.
9. Reinforcement ribs should be welded at the connection between the lamp pole and flange, with a thickness not less than 8mm, and there should be at least 4 reinforcement ribs.
10. The overhead line of the lamp pole should use aviation waxed line with a rated voltage not lower than 500V. The minimum allowable cross-sectional area of the conductor for power below 400W should be 1.5mm², and for power between 400W and 1000W, it should be 2.5mm².
11. The overall wind resistance capability of the lamp pole should be over 30m/s, and the seismic resistance level should be above level 8.
12. The lamp drawing is for reference only. Specific dimensions, colors, processes, etc. are subject to actual survey or owner’s requirements.

Why choose us?

• Our Lighting Pole products are made with expertise and precision.
• Our company follows the quality management system model, has established and improved the quality assurance system, and strongly guarantees the quality and performance of Galvanized Steel Light Pole. Our success lies in not only paying attention to the surface but also pursuing details. Technology is the source of innovation, and innovation is the driving force of development. Our working philosophy is "systematization, specialization, and standardization."
• Our Lighting Poles are made with precision and attention to detail.
• We set up an efficient professional team to achieve personal growth and exceed customer expectations.
• We are a reliable and trustworthy Lighting Pole manufacturer.
• Our company is deeply concerned about the career development of employees and has a complete set of employee development system.
• We provide comprehensive technical support for all our products.
• We could guarantee you product or service good quality and aggressive value for Galvanized Steel Light Pole.
• Our Lighting Poles are tested to ensure they meet all industry standards.
• As a leader in the export industry of Galvanized Steel Light Pole, we have a long-term customer base, including customers from Europe, the Middle East, Asia, the United States, Canada and other regions.

Galvanized Steel Light Pole - A Durable, Reliable and Cost-Effective Solution for Illumination Needs

Are you looking for an efficient and reliable solution for lighting up your outdoor spaces? Would you like to enhance the beauty and safety of your streets, parking lots, parks, plazas, sports fields, and other public spaces while enjoying a long-lasting, low-maintenance, and cost-effective performance? If so, our galvanized steel light poles are the perfect choice for you!

As a leading manufacturer of galvanized steel light poles in China, we have been supplying high-quality and affordable products to customers from all over the world. Our light poles are made of premium-grade materials, including Q235 steel, which is hot-dip galvanized to provide excellent corrosion resistance, rust prevention, and weather protection.

Our galvanized steel light poles are engineered to meet the strictest quality standards and regulations in different countries and industries. We can customize the height, diameter, thickness, and design of our poles to meet your specific needs and preferences. Whether you need tapered, straight, or decorative poles, we have the expertise, equipment, and capacity to deliver the best solutions to you.

Why Choose Our Galvanized Steel Light Poles?

Here are some of the key features and benefits of our galvanized steel light poles that make them stand out from the competition:

1. Durability: Our light poles are made of high-quality materials and are hot-dip galvanized to provide superior corrosion resistance and weatherability. They can withstand extreme temperatures, moisture, winds, and impacts, and retain their strength and stability over time.

2. Versatility: Our light poles are suitable for a variety of applications, including street lighting, security lighting, parking lot lighting, pathway lighting, sports lighting, and decorative lighting. They can accommodate different types of luminaires, such as LED, HID, fluorescent, or incandescent lights, and can be adjusted to different angles and heights.

3. Easy Installation: Our light poles are designed for easy and quick installation with minimal tools and labor. They are shipped in compact and lightweight packages and come with pre-drilled holes, anchor bolts, nuts, washers, and caps. You can follow our installation instructions and videos, or hire a professional installer, to get your light pole up and running in no time.

4. Low Maintenance: Our light poles require little maintenance, thanks to their durable and long-lasting materials and coatings. You may need to clean them periodically to remove dirt, dust, or debris, and check the electrical connections and fixtures for any issues. Otherwise, you can enjoy a hassle-free and cost-effective performance for many years.

5. Environmentally Friendly: Our light poles are made of recyclable materials and comply with environmental regulations and standards. They are energy-efficient and can help reduce carbon emissions, light pollution, and electricity bills. They can also enhance the safety and comfort of pedestrians, cyclists, and motorists while reducing the risk of accidents or crime.

Conclusion

In summary, our galvanized steel light poles are an excellent choice for anyone who wants to light up their outdoor spaces with style, safety, and sustainability. They are durable, versatile, easy to install, low maintenance, and environmentally friendly, and offer a cost-effective and long-lasting performance. Contact us today to learn more about our light poles and get a free quote!
