Square Steel Lamp Post

1. The material of the lamp post is made of Q235 steel, with a wall thickness of δ = 4mm or above. The suppliers are well-known steel manufacturers such as Baosteel and Magang.
2. The lamp post and lamp bracket are hot-dip galvanized inside and outside, with a galvanized layer thickness not less than 85μm. The anti-corrosion lifespan is over 30 years. The surface is treated with DuPont metal paint or spray coating, with a thickness not less than 100μm. Modifications due to straightening or other factors should not exceed 2 locations, and the area of modification should not exceed 5% of the pole surface area.
3. The steel pole should be welded well. Conical poles with a length of 8 meters or below should have no transverse welds, and the longitudinal welds should be symmetrical without any incomplete welding. When placed horizontally without load, the straightness error of the pole should be less than 3‰.
4. For flange-type lamp poles, the allowable length deviation is ±0.5% of the pole length, the allowable cross-sectional dimension deviation is ±0.5%, the deviation in size of the wiring handhole is allowed to be ±5mm, and for once-formed cantilever lamp poles, the allowable deviation in inclination angle is ±1°. After the lamp arm (bracket) is connected and fixed to the lamp pole, the deviation between the center verticality and the pole verticality should not exceed 3°.
5. The inspection door frame of the lamp pole should have reinforcement measures to ensure its mechanical strength is not lower than that without the door frame.
6. The upper end of the inspection door of the lamp pole is equipped with a theft-proof triangle made of φ10mm stainless steel screws, and the lower end is hinged. PE protective wire terminal connectors are welded on the inner wall of the inspection door of the lamp pole.
7. The fastening screws and nuts of the lamp pole and lamp bracket are made of stainless steel.
8. The cable junction box is installed inside the bottom lamp holder crossbar and equipped with RT-14 fuse. For 250W, a 6A fuse is used; for 150W, a 4A fuse is used; for 400W, a 10A fuse is used. The junction box is made of PTFE material.
9. Reinforcement ribs should be welded at the connection between the lamp pole and flange, with a thickness not less than 8mm, and there should be at least 4 reinforcement ribs.
10. The overhead line of the lamp pole should use aviation waxed line with a rated voltage not lower than 500V. The minimum allowable cross-sectional area of the conductor for power below 400W should be 1.5mm², and for power between 400W and 1000W, it should be 2.5mm².
11. The overall wind resistance capability of the lamp pole should be over 30m/s, and the seismic resistance level should be above level 8.
12. The lamp drawing is for reference only. Specific dimensions, colors, processes, etc. are subject to actual survey or owner’s requirements.

Why choose us?

• Our Lighting Poles are built to withstand harsh weather conditions.
• The company will make full use of the traditional advantages of professional design and production of products, and gradually increase the research and development of independent intellectual property rights.
• Our Lighting Pole products are safe and environmentally friendly.
• Our products have gained us widespread acceptance and the satisfaction of our worldwide valued clients.
• Our Lighting Poles are built to withstand extreme weather conditions.
• Our company has gone through three stages of development: from local operation to national operation, then to inward internationalization, and finally to realize the path of internationalization of professional market.
• We provide reliable after-sales service and support.
• Continuously attracting excellent talents is the source of the development of the enterprise and ensures that the enterprise continues to develop new Square Steel Lamp Post.
• We are a reliable and trustworthy Lighting Pole manufacturer.
• We will firmly grasp the corporate development strategy and adhere to the business philosophy of integrity, efficiency, professionalism and steadiness.

Introducing the Square Steel Lamp Post

Are you looking for a reliable and high-quality lighting solution for your outdoor spaces? Look no further than the Square Steel Lamp Post!

Made from premium grade materials, this lamp post is designed to deliver superior performance and longevity. Its square shape not only gives it a distinctive look, but also provides added stability and durability.

Here are some key features and benefits of the Square Steel Lamp Post that make it a great choice for merchants looking to enhance their product offerings:

High-Quality Material: This lamp post is made from top-grade steel, ensuring durability and long-lasting performance. With a thickness of 1.5 mm, it is built to withstand harsh outdoor conditions, including wind, rain, and extreme temperatures.

Cutting-Edge Design: The square shape of the lamp post gives it a sleek and modern look that is perfect for contemporary outdoor spaces. The lamp post comes in a range of sizes to fit different needs and preferences, and can be customized to match specific design requirements.

Versatility: The Square Steel Lamp Post is suitable for a variety of outdoor applications, including home gardens, public parks, and commercial spaces. It can be used to light up walkways, driveways, and other areas that require illumination.

Easy Installation: This lamp post is designed for easy installation, with all necessary hardware included. The post can be easily mounted onto any flat surface, and can be easily wired for power.

Low Maintenance: With its sturdy construction and durable materials, the Square Steel Lamp Post requires minimal maintenance. It is also resistant to corrosion, fading, and other forms of damage, ensuring that it looks great for years to come.

Affordable: Compared to other outdoor lighting solutions, the Square Steel Lamp Post is affordable and cost-effective. This makes it a great choice for merchants looking to offer high-quality products at competitive prices.

In addition to these key features, the Square Steel Lamp Post also offers a range of additional benefits that make it an attractive choice for merchants. These include:

- Aesthetic appeal: The square shape of the lamp post gives it a unique and eye-catching look that is sure to impress customers.

- Ease of use: The lamp post is designed to be easy to use and operate, with simple controls and intuitive functionality.

- Energy efficiency: The lamp post is designed to be energy-efficient, helping to reduce energy costs and minimize environmental impact.

- Customizability: The lamp post can be customized to fit specific needs and preferences, allowing merchants to offer products that are unique and tailored to their customers' needs.

Overall, the Square Steel Lamp Post is a high-quality and versatile outdoor lighting solution that offers a range of benefits and advantages for merchants. Whether you're looking to enhance the lighting in your own outdoor spaces, or you're looking to offer a great product to your customers, the Square Steel Lamp Post is a smart and reliable choice. So why wait? Order yours today and see the difference it can make!
