Modern Street Light Pole

1. The material of the lamp post is made of Q235 steel, with a wall thickness of δ = 4mm or above. The suppliers are well-known steel manufacturers such as Baosteel and Magang.
2. The lamp post and lamp bracket are hot-dip galvanized inside and outside, with a galvanized layer thickness not less than 85μm. The anti-corrosion lifespan is over 30 years. The surface is treated with DuPont metal paint or spray coating, with a thickness not less than 100μm. Modifications due to straightening or other factors should not exceed 2 locations, and the area of modification should not exceed 5% of the pole surface area.
3. The steel pole should be welded well. Conical poles with a length of 8 meters or below should have no transverse welds, and the longitudinal welds should be symmetrical without any incomplete welding. When placed horizontally without load, the straightness error of the pole should be less than 3‰.
4. For flange-type lamp poles, the allowable length deviation is ±0.5% of the pole length, the allowable cross-sectional dimension deviation is ±0.5%, the deviation in size of the wiring handhole is allowed to be ±5mm, and for once-formed cantilever lamp poles, the allowable deviation in inclination angle is ±1°. After the lamp arm (bracket) is connected and fixed to the lamp pole, the deviation between the center verticality and the pole verticality should not exceed 3°.
5. The inspection door frame of the lamp pole should have reinforcement measures to ensure its mechanical strength is not lower than that without the door frame.
6. The upper end of the inspection door of the lamp pole is equipped with a theft-proof triangle made of φ10mm stainless steel screws, and the lower end is hinged. PE protective wire terminal connectors are welded on the inner wall of the inspection door of the lamp pole.
7. The fastening screws and nuts of the lamp pole and lamp bracket are made of stainless steel.
8. The cable junction box is installed inside the bottom lamp holder crossbar and equipped with RT-14 fuse. For 250W, a 6A fuse is used; for 150W, a 4A fuse is used; for 400W, a 10A fuse is used. The junction box is made of PTFE material.
9. Reinforcement ribs should be welded at the connection between the lamp pole and flange, with a thickness not less than 8mm, and there should be at least 4 reinforcement ribs.
10. The overhead line of the lamp pole should use aviation waxed line with a rated voltage not lower than 500V. The minimum allowable cross-sectional area of the conductor for power below 400W should be 1.5mm², and for power between 400W and 1000W, it should be 2.5mm².
11. The overall wind resistance capability of the lamp pole should be over 30m/s, and the seismic resistance level should be above level 8.
12. The lamp drawing is for reference only. Specific dimensions, colors, processes, etc. are subject to actual survey or owner’s requirements.

Why choose us?

• We are committed to providing top-quality Lighting Pole products.
• We always adhere to high standards of production and management, and set more stringent corporate standards based on strict compliance with national and industry standards.
• Our Lighting Poles are built to withstand extreme weather conditions.
• Our world-class main production equipment and technology can fully guarantee our product quality and timely delivery.
• We provide reliable and efficient logistics solutions.
• Our Modern Street Light Poles are sold overseas, and our excellent product quality and perfect service have won wide acclaim from customers at home and abroad.
• We are committed to ensuring customer satisfaction with our products and services.
• We will consistently promote the company's management and corporate governance structure, so that the company and employees grow together, and the company and society develop and advance together.
• We offer competitive pricing without compromising on quality.
• We will continue to be guided by modern footsteps and business management concepts, and aim at sustainable development and mutual benefit and win-win situation.

Introduction:

Modern street light poles are an essential component in modern urban landscapes as they play an important role in improving the quality of life of the people in the cities. They provide adequate lighting during the night and offer a sense of security to the people living in the area. Without modern street light poles, roads, streets, and pavements would be gloomy, and accidents and crimes could easily occur. As a manufacturer in China, we specialize in producing the best quality and most stylish modern street light poles that meet the different needs of our clients.

We have been in the business for several years, and our experience in the industry has enabled us to improve our production processes and, as a result, offer premium quality modern street light poles. Our products are made using advanced technologies and the best quality materials, making them resilient and long-lasting, even in harsh weather conditions.

Design:

We understand that one of the most important aspects that merchants look for when purchasing modern street light poles is design. As such, we have invested heavily in designing our products to meet our client's preferences and expectations. Our modern street light poles come in various designs and sizes, all of which have a sleek and modern finish, making them suitable for various urban and suburban environments. Our poles are available in different colors, including silver, black, white, and chocolate.

Quality:

Quality is an essential aspect that we focus on when producing our modern street light poles. We use high-quality materials to ensure durability and longevity for our products. Our products are made of aluminum, stainless steel, and carbon steel. Each of these materials has unique characteristics. Aluminum is lightweight, making it easy to install while stainless and carbon steel are highly durable, making our poles resistant to rust and corrosion.

Durability:

Our modern street light poles are designed to last for many years and withstand the harshest environments. This is due to the materials and production techniques we use. Our poles are weather-resistant and can withstand natural disasters such as typhoons and earthquakes. Additionally, it can withstand the impact of collisions from vehicles.

Easy Installation and Maintenance:

We understand that merchants want their modern street light poles to be easy to install and maintain. Our poles are designed to be easily installed, and they come with installation manuals that are easy to follow. Additionally, our poles are easy to maintain as they come with easy-to-follow maintenance guides, and the materials used to produce our poles are resistant to natural wear and tear.

Reasonable Pricing:

While we offer premium quality modern street light poles, we ensure that our prices are reasonable. We value our clients' satisfaction, and we believe that the prices we set for our products reflect our commitment to serving them. As such, our prices are competitive in the market.

Conclusion:

In conclusion, our modern street light poles are designed with the needs of our clients in mind. Our poles are available in various designs, sizes, and colors. They are made of high-quality materials, which makes them durable, weather-resistant, and easy to maintain. Our poles are easy to install, and our prices are reasonable. By choosing us, you are guaranteed to receive premium quality modern street light poles that meet your specific needs. Contact us now to place your order or inquire about our products!
