Direct Burial Lamp Post

1. The lamp post material is made of Q235 steel with a wall thickness of δ=4mm or above. The suppliers are well-known steel manufacturers such as Baosteel and Magang.
2. The lamp post and lamp bracket are hot-dip galvanized inside and outside, with a galvanized layer thickness not less than 85μm. The anti-corrosion lifespan is over 30 years. The surface is treated with DuPont metal paint or spray coating, with a thickness not less than 100μm. Modifications due to straightening or other factors should not exceed 2 locations, and the area of modification should not exceed 5% of the pole surface area.
3. The steel pole should be welded well. Conical poles with a length of 8 meters or below should have no transverse welds, and the longitudinal welds should be symmetrical without any incomplete welding. When placed horizontally without load, the straightness error of the pole should be less than 3‰.
4. For flange-type lamp poles, the allowable length deviation is ±0.5% of the pole length, the allowable cross-sectional dimension deviation is ±0.5%, the deviation in size of the wiring handhole is allowed to be ±5mm, and for once-formed cantilever lamp poles, the allowable deviation in inclination angle is ±1°. After the lamp arm (bracket) is connected and fixed to the lamp pole, the deviation between the center verticality and the pole verticality should not exceed 3°.
5. The inspection door frame of the lamp pole should have reinforcement measures to ensure its mechanical strength is not lower than that without the door frame.
6. The upper end of the inspection door of the lamp pole is equipped with a theft-proof triangle made of φ10mm stainless steel screws, and the lower end is hinged. PE protective wire terminal connectors are welded on the inner wall of the inspection door of the lamp pole.
7. The fastening screws and nuts of the lamp pole and lamp bracket are made of stainless steel.
8. The cable junction box is installed inside the bottom lamp holder crossbar and equipped with RT-14 fuse. For 250W, a 6A fuse is used; for 150W, a 4A fuse is used; for 400W, a 10A fuse is used. The junction box is made of PTFE material.
9. Reinforcement ribs should be welded at the connection between the lamp pole and flange, with a thickness not less than 8mm, and there should be at least 4 reinforcement ribs.
10. The overhead line of the lamp pole should use aviation waxed line with a rated voltage not lower than 500V. The minimum allowable cross-sectional area of the conductor for power below 400W should be 1.5mm², and for power between 400W and 1000W, it should be 2.5mm².
11. The overall wind resistance capability of the lamp pole should be over 30m/s, and the seismic resistance level should be above level 8.
12. The lamp drawing is for reference only. Specific dimensions, colors, processes, etc. are subject to actual survey or owner’s requirements.

Why choose us?

• We provide a wide range of Lighting Pole products to meet different requirements.
• We always take customers as the center and meet their needs as the purpose, and make unremitting efforts to win more customers and world famous brands.
• Our Lighting Poles are easy to install and low-maintenance.
• We vigorously expand the domestic and foreign markets, strive to climb the peak of the Direct Burial Lamp Post industry, and develop towards modularization, groupization and internationalization.
• Our Lighting Pole products are safe and environmentally friendly.
• 'Based on domestic market and expand overseas business' is our improvement strategy for Direct Burial Lamp Post.
• We offer competitive pricing with no compromise on quality.
• Loyalty and integrity is the principle we always believe in, loyalty, morality, honesty and trustworthiness are our solemn promises to customers.
• We provide customized packaging solutions to protect your products during transport.
• Our company implements the internationalization strategy, seeks the overseas agent, establishes the strategic cooperation partnership.

Introducing the Direct Burial Lamp Post – The Ultimate Solution for Outdoor Lighting!

Are you looking to enhance the ambiance of your outdoor area with the perfect lighting solution? If so, then you've come to the right place! We are one of the most reputed manufacturers in China, and we wholesale a range of high-quality products to countries outside of China. Our Direct Burial Lamp Post is a premium lighting solution that has become incredibly popular among our clients for its superior quality and unmatched features.

What is the Direct Burial Lamp Post?

The Direct Burial Lamp Post is a sturdy, durable, and reliable outdoor lighting solution that is designed to withstand the toughest weather conditions. It has a unique dual-layer design that enhances its structural integrity and helps protect it from wear and tear caused by weather conditions. The lamp post is made of high-quality, corrosion-resistant materials that ensure it lasts you for years to come.

Features and Benefits of Direct Burial Lamp Post

Durability and Resistance to Wear and Tear

The Direct Burial Lamp Post is designed to resist wear and tear, making it perfect for harsh weather conditions, including sunlight, rain, snow, sleet, and strong winds. The lamp post is made from high-quality materials that are specifically formulated to withstand these harsh elements. The post does not rot or corrode, making it suitable for use in any environment.

Ease of Installation

Our Direct Burial Lamp Post is designed to make the installation process as simple as possible. There is no need to worry about mounting the lamp post with bolts, screws, or any other brackets, as it is embedded directly into the ground. The installation is straightforward and can be done easily by anyone.

Versatility

The lamp post is highly versatile and can be used in a variety of applications and environments. It can be used in private or public areas, parks, sports centers, commercial and residential areas, parking lots, and so on.

Energy Efficient

Our Direct Burial Lamp Post is designed to be energy-efficient, which means that you can save on energy bills while providing effective lighting. The posts are compatible with LED bulbs and other energy-efficient bulbs that provide bright illumination while also saving energy.

Multiple Configurations

Our Direct Burial Lamp Post is designed to meet the needs of different customers. We can configure the lamp post to meet your requirements and specifications, including color, height, and style.

Why Choose Our Direct Burial Lamp Post?

Our Direct Burial Lamp Post has become incredibly popular among our clients, and there are several reasons why. Firstly, we manufacture our lamp posts using high-quality, durable materials that ensure the longevity and reliability of the product. Secondly, we offer multiple configurations, and our team can customize the product to meet your specific needs and specifications.

Additionally, our lamp posts are energy-efficient, making them a great investment that will save you money in the long run. Finally, the posts are highly versatile and can be used in a range of applications and environments.

Conclusion

In conclusion, the Direct Burial Lamp Post is a reliable, durable, and energy-efficient outdoor lighting solution that is perfect for anyone looking to enhance the ambiance of their outdoor space. Our lamp post is made of high-quality materials, has multiple configurations, and is easy to install. It is also energy-efficient, versatile, and highly reliable, making it a great investment for anyone looking for a long-term lighting solution. Contact us today to learn more about how the Direct Burial Lamp Post can be tailored to your specific needs and requirements!
