Cast Iron Garden Lamp Post

1. The material of the lamp post is Q235 steel, with a wall thickness of δ = 4mm or above. The suppliers are well-known steel manufacturers such as Baosteel and Magang.
2. The lamp post and lamp bracket are hot-dip galvanized inside and outside, with a galvanized layer thickness not less than 85μm. The anti-corrosion lifespan is over 30 years. The surface is treated with DuPont metal paint or spray coating, with a thickness not less than 100μm. Modifications due to straightening or other factors should not exceed 2 locations, and the area of modification should not exceed 5% of the pole surface area.
3. The steel pole should be welded well. Conical poles with a length of 8 meters or below should have no transverse welds, and the longitudinal welds should be symmetrical without any incomplete welding. When placed horizontally without load, the straightness error of the pole should be less than 3‰.
4. For flange-type lamp poles, the allowable length deviation is ±0.5% of the pole length, the allowable cross-sectional dimension deviation is ±0.5%, the deviation in size of the wiring handhole is allowed to be ±5mm, and for once-formed cantilever lamp poles, the allowable deviation in inclination angle is ±1°. After the lamp arm (bracket) is connected and fixed to the lamp pole, the deviation between the center verticality and the pole verticality should not exceed 3°.
5. The inspection door frame of the lamp pole should have reinforcement measures to ensure its mechanical strength is not lower than that without the door frame.
6. The upper end of the inspection door of the lamp pole is equipped with a theft-proof triangle made of φ10mm stainless steel screws, and the lower end is hinged. PE protective wire terminal connectors are welded on the inner wall of the inspection door of the lamp pole.
7. The fastening screws and nuts of the lamp pole and lamp bracket are made of stainless steel.
8. The cable junction box is installed inside the bottom lamp holder crossbar and equipped with RT-14 fuse. For 250W, a 6A fuse is used; for 150W, a 4A fuse is used; for 400W, a 10A fuse is used. The junction box is made of PTFE material.
9. Reinforcement ribs should be welded at the connection between the lamp pole and flange, with a thickness not less than 8mm, and there should be at least 4 reinforcement ribs.
10. The overhead line of the lamp pole should use aviation waxed line with a rated voltage not lower than 500V. The minimum allowable cross-sectional area of the conductor for power below 400W should be 1.5mm², and for power between 400W and 1000W, it should be 2.5mm².
11. The overall wind resistance capability of the lamp pole should be over 30m/s, and the seismic resistance level should be above level 8.
12. The lamp drawing is for reference only. Specific dimensions, colors, processes, etc. are subject to actual survey or owner’s requirements.

Why choose us?

• We are a Chinese factory that produces high-quality Lighting Poles.
• Our company will closely focus on serving the country's strategic goals, take policy as the guide, and take customers as the center to build the company into a responsible, reliable and globally influential credit risk management institution, serving the country's new round of high-level external Open up to make new and greater contributions.
• Our Lighting Poles are known for their durability and longevity.
• Professional R & D team, many years of market experience, let us have confidence in our Cast Iron Garden Lamp Post.
• We provide a one-stop-shop for all your Lighting Pole needs.
• The company has always followed the principles of integrity, quality and service, and insisted on providing customers with high-quality products, services and good after-sales service.
• We are committed to providing top-quality Lighting Pole products.
• We are committed to innovation, manufacturing new and excellent Cast Iron Garden Lamp Post and strive to provide customers with effective solutions.
• We prioritize customer satisfaction above all else.
• We actively integrate various development resources, adjust the economic structure and extend the industrial chain.

Cast Iron Garden Lamp Post: A perfect blend of beauty and durability

Gardening is more than just a hobby, it's an art that requires passion, patience and creativity. A perfect garden demands the right balance of colors, plants and decorative elements. While flowers and plants add natural beauty to a garden, decorative elements enhance the overall appeal of the space. Lighting is one such important element that can uplift the beauty of your garden and cast a spell on your visitors. A cast iron garden lamp post is a perfect way to add glamour and elegance to your garden.

Our cast iron garden lamp post is designed keeping in mind the needs of gardening enthusiasts who crave for vintage styles and timeless designs. It is made of high-quality cast iron that can withstand harsh outdoor weather and retain its beauty for years to come. The lamp post has a height of 2.1 meters and is supported on a sturdy base to provide maximum stability. It is designed to hold a standard bulb socket and can illuminate an area of up to 5 meters.

The cast iron garden lamp post comes with a detachable lamp head and a glass shade that provides an exquisite appearance to the lamp. The lamp post is compatible with LED bulbs, which consume less energy and emit brighter light than traditional bulbs. The lamp can be controlled by a switch, which makes it convenient to use. Moreover, the cast iron garden lamp post comes with a powder-coated finish that protects it from rust and other environmental hazards.

Our lamp post is not only beautiful but also easy to install. It can be assembled and installed by anyone, with no special tools required. The lamp post can be mounted on any flat surface or buried in the ground. It comes with an easy-to-understand instruction manual, which guides you through the installation process. Moreover, our customer support team is always there to assist you in case of any queries or problems.

Our cast iron garden lamp post is perfect for residential and commercial properties, including hotels, resorts, golf courses, parks, and private gardens. It adds a warm glow to your space, making it perfect for evening gatherings, barbeques, and outdoor parties. It is an ideal way to light up your walkways, driveways, and pathways, making your garden look more welcoming and safe.

In conclusion, our cast iron garden lamp post is a timeless piece of art that can transform your garden into a mesmerizing paradise. With its vintage style, it creates an enchanting atmosphere that will leave your guests spellbound. Its durability, ease of installation and low maintenance make it a popular choice among garden enthusiasts worldwide. So, if you're looking to add a touch of elegance and glamour to your garden, our cast iron garden lamp post is the perfect choice for you.
