Galvanized Aluminum Polygonal Monitoring Rod

Cross arm pole (lever), hoop picking pole:
The cross arm pole (lever) and hoop picking pole have a diameter of ≥60mm and extend 0.5-4 meters. They are made of seamless steel pipe with a wall thickness ≥3mm. The surface is hot-dip galvanized and electrostatically sprayed. Different types of poles and construction methods should be selected according to actual conditions.

Community standing pole:

1. L-shaped standing pole with a height of 3 meters/3.5 meters/4 meters, variable diameter pole. The main pole has a length of 1 meter and a diameter of 140mm, while the remaining part has a length and a diameter of 76mm. The arm length is 0.5 meters. The main pole thickness is ≥4mm. The average diameter of the hoop pole is ≥60mm with a pipe wall thickness of ≥3mm.
2. The pole material is Q235, and welding should be done using automatic butt fusion submerged arc welding. The weld should be even, continuous, beautiful, strong in penetration, and formed in one pass.
3. The pole should be free from rust and undergo overall hot-dip galvanizing treatment after processing. The galvanized layer surface should be smooth and beautiful, without wrinkles, sagging, zinc tumors, peeling, spots, or defects on the positive and negative sides. The hot-dip galvanizing should comply with national standards, and the galvanized layer thickness should be ≥85μm, ensuring no rust for 20 years.
4. High-quality outdoor powder coating should be selected to perform electrostatic spray treatment on the galvanized pole body. The spray coating thickness should be ≥0.5mm and uniform in color.
5. The lower end of the pole should have a maintenance door with specifications of 200*90mm, using internal hexagon bolts.

Equal-diameter pole 3-4 meters:

1. L-shaped standing pole with a height of 3 meters or 4 meters and an arm length of 1-3 meters. The standing pole is made of equal-diameter pole with a diameter ≥120mm and a main pole thickness ≥4mm. The average diameter of the hoop pole is ≥60mm with a pipe wall thickness ≥3mm. There is a 50cm reflective strip around the pole body.
2. The pole material is Q235, and welding should be done using automatic butt fusion submerged arc welding. The weld should be even, continuous, beautiful, strong in penetration, and formed in one pass.
3. The pole should be free from rust and undergo overall hot-dip galvanizing treatment after processing. The galvanized layer surface should be smooth and beautiful, without wrinkles, sagging, zinc tumors, peeling, spots, or defects on the positive and negative sides. The hot-dip galvanizing should comply with national standards, and the galvanized layer thickness should be ≥85μm, ensuring no rust for 20 years.
4. High-quality outdoor powder coating should be selected to perform electrostatic spray treatment on the galvanized pole body. The spray coating thickness should be ≥0.5mm and uniform in color.

Octagonal pole 3-4 meters:

1. The straight pole has a height of 3-4 meters and extends 0.5-3 meters. It is made of octagonal pole with a bottom outer diameter ≥150mm and a top diameter ≥100mm. The suspension pole has a diameter ≥76mm. There is a 50cm reflective strip around the pole body.
2. The main pole thickness is ≥4mm, and the suspension pole thickness is ≥3mm. They are both hot-dip galvanized, plastic-coated, and painted.
3. The pole material is Q235, and welding should be done using automatic butt fusion submerged arc welding. The weld should be even, continuous, beautiful, strong in penetration, and formed in one pass.
4. The pole should be free from rust and undergo overall hot-dip galvanizing treatment after processing. The galvanized layer surface should be smooth and beautiful, without wrinkles, sagging, zinc tumors, peeling, spots, or defects on the positive and negative sides. The hot-dip galvanizing should comply with national standards, and the galvanized layer thickness should be ≥85μm, ensuring no rust for 20 years.
5. High-quality outdoor powder coating should be selected to perform electrostatic spray treatment on the galvanized pole body. The spray coating thickness should be ≥0.5mm and uniform in color.

Octagonal pole 5 meters:

1. The straight pole has a height of 5 meters and extends 0.5-3 meters. It is made of octagonal pole with a bottom outer diameter ≥180mm and a top diameter ≥130mm. The suspension pole has a diameter ≥76mm. There is a 50cm reflective strip around the pole body.
2. The main pole thickness is ≥4mm, and the suspension pole thickness is ≥3mm. They are both hot-dip galvanized, plastic-coated, and painted.
3. The pole material is Q235, and welding should be done using automatic butt fusion submerged arc welding. The weld should be even, continuous, beautiful, strong in penetration, and formed in one pass.
4. The pole should be free from rust and undergo overall hot-dip galvanizing treatment after processing. The galvanized layer surface should be smooth and beautiful, without wrinkles, sagging, zinc tumors, peeling, spots, or defects on the positive and negative sides. The hot-dip galvanizing should comply with national standards, and the galvanized layer thickness should be ≥85μm, ensuring no rust for 20 years.
5. High-quality outdoor powder coating should be selected to perform electrostatic spray treatment on the galvanized pole body. The spray coating thickness should be ≥0.5mm and uniform in color.

Equal-diameter pole 5-6 meters:

1. L-shaped standing pole with a height of 6 meters and an arm length of 1-5 meters. The standing pole is made of equal-diameter pole with a diameter ≥220mm and a wall thickness ≥6mm. The average diameter of the hoop pole is ≥114mm, and the pipe wall thickness is ≥6mm. There is a 50cm reflective strip around the pole body.
2. The pole material is Q235, and welding should be done using automatic butt fusion submerged arc welding. The weld should be even, continuous, beautiful, strong in penetration, and formed in one pass.
3. The pole should be free from rust and undergo overall hot-dip galvanizing treatment after processing. The galvanized layer surface should be smooth and beautiful, without wrinkles, sagging, zinc tumors, peeling, spots, or defects on the positive and negative sides. The hot-dip galvanizing should comply with national standards, and the galvanized layer thickness should be ≥85μm, ensuring no rust for 20 years.
4. High-quality outdoor powder coating should be selected to perform electrostatic spray treatment on the galvanized pole body. The spray coating thickness should be ≥0.5mm and uniform in color.

L6 pick 1-5 meters:

1. The straight pole is 6 meters high and picks 1-5 meters, using an octagonal pole. The bottom outer diameter of the straight pole should be ≥260mm and the top should be ≥220mm. The hanging pole outer diameter should be ≥150mm and the top should be ≥100mm. A 50cm reflective strip should be wrapped around the pole body.
2. The main pole wall thickness should be ≥6mm. The hanging pole wall thickness should be ≥4mm. They should be hot-dip galvanized, plastic-coated, and painted.
3. The pole components should be made of Q235 material. Welding should use automatic butt joint submerged arc welding, with uniform, continuous, aesthetically pleasing welds and strong penetration, forming in one pass.
4. The pole components should be free from rust and should undergo overall hot-dip galvanizing treatment after processing. The surface of the galvanized layer should be smooth and beautiful, without wrinkles, drips, zinc tumors, peeling, spots, or defects on the front and back surfaces. The hot-dip galvanizing should comply with national standards, and the thickness of the galvanized layer should be ≥85μm to ensure 20 years of corrosion resistance.
5. High-quality outdoor powder coating should be selected, and the already galvanized pole body should undergo electrostatic spray coating treatment with a coating thickness of ≥0.5mm for a uniform color appearance.

L6-6 pick 6 meters:

1. The straight pole is 6 meters high and picks 6 meters, using an octagonal pole. The bottom outer diameter of the straight pole should be ≥285mm and the top should be ≥220mm. The hanging pole outer diameter should be ≥170mm and the top should be ≥100mm. A 50cm reflective strip should be wrapped around the pole body.
2. The main pole wall thickness should be ≥6mm. The hanging pole wall thickness should be ≥6mm. They should be hot-dip galvanized, plastic-coated, and painted.
3. The pole components should be made of Q235 material. Welding should use automatic butt joint submerged arc welding, with uniform, continuous, aesthetically pleasing welds and strong penetration, forming in one pass.
4. The pole components should be free from rust and should undergo overall hot-dip galvanizing treatment after processing. The surface of the galvanized layer should be smooth and beautiful, without wrinkles, drips, zinc tumors, peeling, spots, or defects on the front and back surfaces. The hot-dip galvanizing should comply with national standards, and the thickness of the galvanized layer should be ≥85μm to ensure 20 years of corrosion resistance.
5. High-quality outdoor powder coating should be selected, and the already galvanized pole body should undergo electrostatic spray coating treatment with a coating thickness of ≥0.5mm for a uniform color appearance.

L6 pick 7-8 meters:

1. The straight pole is 6 meters high and picks from 7 to 8 meters, using an octagonal pole. The bottom outer diameter of the straight pole should be ≥285mm and the top should be ≥220mm. The hanging pole outer diameter should be ≥220mm and the top should be ≥100mm. A 50cm reflective strip should be wrapped around the pole body.
2. The main pole wall thickness should be ≥8mm. The hanging pole wall thickness should be ≥6mm. They should be hot-dip galvanized, plastic-coated, and painted.
3. The pole components should be made of Q235 material. Welding should use automatic butt joint submerged arc welding, with uniform, continuous, aesthetically pleasing welds and strong penetration, forming in one pass.
4. The pole components should be free from rust and should undergo overall hot-dip galvanizing treatment after processing. The surface of the galvanized layer should be smooth and beautiful, without wrinkles, drips, zinc tumors, peeling, spots, or defects on the front and back surfaces. The hot-dip galvanizing should comply with national standards, and the thickness of the galvanized layer should be ≥85μm to ensure 20 years of corrosion resistance.
5. High-quality outdoor powder coating should be selected, and the already galvanized pole body should undergo electrostatic spray coating treatment with a coating thickness of ≥0.5mm for a uniform color appearance.

L6 pick 9-10 meters:

1. The straight pole is 6 meters high and picks from 9 to 10 meters, using an octagonal pole. The bottom outer diameter of the straight pole should be ≥285mm and the top should be ≥220mm. The hanging pole outer diameter should be ≥250mm and the top should be ≥100mm. A 50cm reflective strip should be wrapped around the pole body.
2. The main pole wall thickness should be ≥8mm. The hanging pole wall thickness should be ≥6mm. They should be hot-dip galvanized, plastic-coated, and painted.
3. The pole components should be made of Q235 material. Welding should use automatic butt joint submerged arc welding, with uniform, continuous, aesthetically pleasing welds and strong penetration, forming in one pass.
4. The pole components should be free from rust and should undergo overall hot-dip galvanizing treatment after processing. The surface of the galvanized layer should be smooth and beautiful, without wrinkles, drips, zinc tumors, peeling, spots, or defects on the front and back surfaces. The hot-dip galvanizing should comply with national standards, and the thickness of the galvanized layer should be ≥85μm to ensure 20 years of corrosion resistance.
5. High-quality outdoor powder coating should be selected, and the already galvanized pole body should undergo electrostatic spray coating treatment with a coating thickness of ≥0.5mm for a uniform color appearance.

L6.5 pick 7-8 meters:

1. The straight pole is 6.5 meters high and picks from 7 to 8 meters, using an octagonal pole. The outer diameter of the straight pole should be ≥320mm at the bottom and ≥260mm at the top. The hanging pole outer diameter should be ≥220mm and the top should be ≥100mm. A 50cm reflective strip should be wrapped around the pole body.
2. The main pole wall thickness should be ≥8mm. The hanging pole wall thickness should be ≥6mm. They should be hot-dip galvanized, plastic-coated, and painted.
3. The pole components should be made of Q235 material. Welding should use automatic butt joint submerged arc welding, with uniform, continuous, aesthetically pleasing welds and strong penetration, forming in one pass.
4. The pole components should be free from rust and should undergo overall hot-dip galvanizing treatment after processing. The surface of the galvanized layer should be smooth and beautiful, without wrinkles, drips, zinc tumors, peeling, spots, or defects on the front and back surfaces. The hot-dip galvanizing should comply with national standards, and the thickness of the galvanized layer should be ≥85μm to ensure 20 years of corrosion resistance.
5. High-quality outdoor powder coating should be selected, and the already galvanized pole body should undergo electrostatic spray coating treatment with a coating thickness of ≥0.5mm for a uniform color appearance.

L6.5 9-10 meters:

1. The straight pole is 6.5 meters high and extends 10 meters. It uses an octagonal pole with an outer diameter of ≥320mm at the top and ≥260mm at the bottom. The suspension pole has an outer diameter of ≥250mm at the top and ≥100mm at the bottom. A 50cm reflective strip should be wrapped around the pole body.
2. The main pole should have a wall thickness of ≥8mm, and the suspension pole should have a wall thickness of ≥6mm. Both poles should be hot-dip galvanized and coated with paint.
3. The pole components should be made of Q235 material, and automatic submerged arc welding should be used for welding to ensure even and aesthetically pleasing welds with strong penetration and one-time forming.
4. The pole components should be free from rusting and undergo overall hot-dip galvanizing treatment after processing. The surface of the galvanized layer should be smooth and free from wrinkles, drips, zinc nodules, peeling, spots, or defects in the anodic and cathodic surfaces. The galvanizing should comply with national standards, and the thickness of the galvanized layer should be ≥85μm to guarantee no rusting for 20 years.
5. High-quality outdoor powder coating should be selected to electrostatically spray the already galvanized pole body with a coating thickness of ≥0.5mm and uniform color.

L6.5 11-12 meters:

1. The straight pole is 6 meters high and extends 11 to 12 meters. It uses an octagonal pole with a bottom outer diameter of ≥340mm and a top outer diameter of ≥280mm. The suspension pole has an outer diameter of ≥230mm at the top and ≥110mm at the bottom. A 50cm reflective strip should be wrapped around the pole body.
2. The main pole should have a wall thickness of ≥10mm, and the suspension pole should have a wall thickness of ≥6mm. Both poles should be hot-dip galvanized and coated with paint.
3. The pole components should be made of Q235 material, and automatic submerged arc welding should be used for welding to ensure even and aesthetically pleasing welds with strong penetration and one-time forming.
4. The pole components should be free from rusting and undergo overall hot-dip galvanizing treatment after processing. The surface of the galvanized layer should be smooth and free from wrinkles, drips, zinc nodules, peeling, spots, or defects in the anodic and cathodic surfaces. The galvanizing should comply with national standards, and the thickness of the galvanized layer should be ≥85μm to guarantee no rusting for 20 years.
5. High-quality outdoor powder coating should be selected to electrostatically spray the already galvanized pole body with a coating thickness of ≥0.5mm and uniform color.

Equal diameter pole 4.5-0.6 meters:

1. The L-shaped vertical pole is 4.5 meters high with an outreach length of 0.6 meters. The vertical pole should have an equal diameter of ≥160mm and a main pole thickness of ≥6mm. The average pipe diameter of the outreach pole should be ≥89mm, and the pipe wall thickness should be ≥3mm.
2. The pole components should be made of Q235 material, and automatic submerged arc welding should be used for welding to ensure even and aesthetically pleasing welds with strong penetration and one-time forming.
3. The pole components should be free from rusting and undergo overall hot-dip galvanizing treatment after processing. The surface of the galvanized layer should be smooth and free from wrinkles, drips, zinc nodules, peeling, spots, or defects in the anodic and cathodic surfaces. The galvanizing should comply with national standards, and the thickness of the galvanized layer should be ≥85μm to guarantee no rusting for 20 years.
4. High-quality outdoor powder coating should be selected to electrostatically spray the already galvanized pole body with a coating thickness of ≥0.5mm and uniform color.
