Integrated Slim Smart Lamp Post

1. The lamp post is made of Q235 steel with a thickness of δ=4mm or more. The suppliers are well-known steel mills such as Baosteel and Magang.
2. The lamp post and bracket are hot-dip galvanized both inside and outside, with a galvanized layer thickness of not less than 85μm. The anti-corrosion lifespan is more than 30 years. The surface is treated with DuPont metal paint or spray, with a thickness of not less than 100μm. The number of modified parts due to straightening or other factors should not exceed 2, and the area for modification should not exceed 5% of the pole surface area.
3. The steel pole should be well welded. For tapered poles with a length of 8 meters or less, there should be no transverse welds, and the longitudinal welds should be symmetrical and without incomplete penetration. Under the condition of horizontal placement and no load, the straightness deviation of the pole body should be less than 3‰.
4. For flange-type lamp posts, the allowable deviation in pole length is ±0.5% of the pole length, the allowable deviation in cross-sectional dimensions of the pole body is ±0.5%, the allowable deviation in wiring hand hole size is ±5mm, the allowable deviation in the tilt angle of one-piece cantilever lamp poles is ±1°, and after the lamp arm (bracket) is connected and fixed to the lamp post, the deviation between the center verticality and the verticality of the lamp post should not exceed 3°.
5. The inspection door frame of the lamp post should have reinforcement measures to ensure that its mechanical strength is not lower than the strength when the door is closed.
6. The upper end of the inspection door of the lamp post is equipped with an anti-theft triangular stainless steel screw with a diameter of Φ10mm, and the lower end is hinged. The inner wall of the inspection door of the lamp post is welded with PE protection wire terminal.
7. The fastening screws and nuts of the lamp post and bracket are made of stainless steel.
8. The cable junction box is installed inside the bottom lamp holder crossbar, equipped with RT-14 fuse, 250W equipped with 6A fuse, 150W equipped with 4A fuse, 400W equipped with 10A fuse. The junction box is made of PTFE material.
9. The welding reinforcement ribs are required at the connection between the lamp post and the flange, with a thickness of not less than 8mm and a minimum of 4 reinforcement ribs.
10. The overhead line of the lamp post should use aviation waxed line with a rated voltage of not less than 500V. The minimum allowable cross-sectional area of the line core for power less than 400W should be 1.5mm², and the minimum allowable cross-sectional area of the line core for power from 400W to 1000W should be 2.5mm².
11. The overall wind resistance of the lamp post is above 30 m/s, and the seismic grade is above 8.
12. The lamp model drawing is for reference only. The specific dimensions, colors, processes, etc. should be based on actual survey or owner’s requirements.

Why choose us?

• We are a Chinese factory with a focus on producing high-quality Smart Lamp Post products and providing professional services.
• We have refined and perfected our products with the ultimate attitude, which has made our company a unique brand.
• We believe that our commitment to high-quality manufacturing and service sets us apart from other Smart Lamp Post suppliers.
• We need to improve the value of our Integrated Slim Smart Lamp Post to meet the needs of users through technological innovation.
• We are committed to providing our customers with exceptional Smart Lamp Post products and services, delivered with integrity and professionalism.
• The staff makes the team brilliant, and the company helps me grow in life.
• Our Smart Lamp Post products are designed to be energy-efficient and environmentally friendly.
• We provide sustainable product solutions for our customers with a professional and responsible attitude.
• Our Smart Lamp Post products are designed to improve the safety and efficiency of public spaces, making them ideal for city planners and local governments.
• As long as their product quality passes the customs and users are satisfied, they can have the hard strength in the market.

Introduction:

The Integrated Slim Smart Lamp Post is a perfect example of innovation meeting function. It is an advanced urban lighting solution that combines energy efficiency, high performance, and elegant design. This product brings together the latest technology, quality manufacturing, and environmental sustainability, all packaged into one impressive lamp.

Features:

The Integrated Slim Smart Lamp Post is made of high-quality materials, including aluminum alloy and PC lens, which are long-lasting and perfect for outdoor use. It features a top-mounted solar panel and mounting bracket that allows for easy and secure installation on lamp posts, walls, or any other vertical surfaces. The modular design of this lamp makes it easy to install and maintain, while also reducing material waste.

Energy Efficiency:

This smart lamp post is powered by solar energy, which means that it is an environmentally friendly lighting solution that saves on energy costs. It features a high-efficiency LED light source that provides bright, clear light while consuming minimal power. The lamp's motion sensor feature can detect the presence of pedestrians and automatically turn on/off, further reducing energy consumption. The solar panel at the top of the lamp post charges the battery during the day, ensuring that the lamp stays on throughout the night. This feature also ensures that there is no need to run cables or trenching work, reducing installation time and cost.

Versatility:

The Integrated Slim Smart Lamp Post is suitable for use in various settings, including residential, commercial, and industrial areas. Whether used in streets, parks, parking lots, entrances, or any other outdoor areas, this lamp post will provide reliable lighting throughout the night. Its modular design makes it easy to install, upgrade, and maintain, and it can withstand harsh outdoor conditions such as rain, snow, and extreme temperatures.

Durability:

The Integrated Slim Smart Lamp Post is designed to last for a long time, and it is highly durable. The lamp comes with IP65 waterproof and anti-UV protection, preventing exposure to the wind, sun, and rain. This durability feature means that the lamp post outdoor will be protected and continuously provide high-performance illumination throughout the year.

Cost-Effective:

The Integrated Slim Smart Lamp Post is an economical lighting solution that saves on energy costs while providing bright and reliable lighting. The installation and maintenance cost of this product are low compared to other forms of outdoor lighting, such as traditional streetlights that require expensive wiring and trenching work. Plus, the solar energy-powered feature ensures there are no electricity bills and low maintenance costs.

Conclusion:

In conclusion, the Integrated Slim Smart Lamp Post is a revolutionary urban lighting solution that is both innovative and functional. It is a perfect example of how technology can address sustainable development challenges, providing a reliable, cost-effective, and environmentally sustainable solution for outdoor lighting needs. This lamp post is easy to install, energy efficient, and long-lasting, making it an ideal product for both merchants and end-users. Get your hands on this energy-efficient and cost-effective product and enjoy a well-lit surrounding powered by the sun.
