High Power Explosion Proof Garden Light

1. The lamp post is made of Q235 steel with a thickness of δ=4mm or more. The suppliers are well-known steel mills such as Baosteel and Magang.
2. The lamp post and bracket are hot-dip galvanized both inside and outside, with a galvanized layer thickness of not less than 85μm. The anti-corrosion lifespan is more than 30 years. The surface is treated with DuPont metal paint or spray, with a thickness of not less than 100μm. The number of modified parts due to straightening or other factors should not exceed 2, and the area for modification should not exceed 5% of the pole surface area.
3. The steel pole should be well welded. For tapered poles with a length of 8 meters or less, there should be no transverse welds, and the longitudinal welds should be symmetrical and without incomplete penetration. Under the condition of horizontal placement and no load, the straightness deviation of the pole body should be less than 3‰.
4. For flange-type lamp posts, the allowable deviation in pole length is ±0.5% of the pole length, the allowable deviation in cross-sectional dimensions of the pole body is ±0.5%, the allowable deviation in wiring hand hole size is ±5mm, the allowable deviation in the tilt angle of one-piece cantilever lamp poles is ±1°, and after the lamp arm (bracket) is connected and fixed to the lamp post, the deviation between the center verticality and the verticality of the lamp post should not exceed 3°.
5. The inspection door frame of the lamp post should have reinforcement measures to ensure that its mechanical strength is not lower than the strength when the door is closed.
6. The upper end of the inspection door of the lamp post is equipped with an anti-theft triangular stainless steel screw with a diameter of Φ10mm, and the lower end is hinged. The inner wall of the inspection door of the lamp post is welded with PE protection wire terminal.
7. The fastening screws and nuts of the lamp post and bracket are made of stainless steel.
8. The cable junction box is installed inside the bottom lamp holder crossbar, equipped with RT-14 fuse, 250W equipped with 6A fuse, 150W equipped with 4A fuse, 400W equipped with 10A fuse. The junction box is made of PTFE material.
9. The welding reinforcement ribs are required at the connection between the lamp post and the flange, with a thickness of not less than 8mm and a minimum of 4 reinforcement ribs.
10. The overhead line of the lamp post should use aviation waxed line with a rated voltage of not less than 500V. The minimum allowable cross-sectional area of the line core for power less than 400W should be 1.5mm², and the minimum allowable cross-sectional area of the line core for power from 400W to 1000W should be 2.5mm².
11. The overall wind resistance of the lamp post is above 30 m/s, and the seismic grade is above 8.
12. The lamp model drawing is for reference only. The specific dimensions, colors, processes, etc. should be based on actual survey or owner’s requirements.

Why choose us?

• Our manufacturing facility adheres to strict safety standards to ensure the wellbeing of our workers and customers.
• The products produced by our company are simple in operation, convenient in maintenance, and in place after-sales service, which have won unanimous praise from new and old customers.
• Our company has many years of experience in the garden lighting industry, making us experts in the field.
• In recent years, we have continuously developed new products, just to meet the more diverse needs of our customers.
• Our garden lamps and lights are eco-friendly and contribute to reducing carbon footprints.
• We adhere to the management policy of "effective service, on-time delivery, quality first" and "zero defect, zero complaint" as the quality objectives.
• Our garden lamps and lights are designed with safety in mind to avoid accidents in outdoor spaces.
• We are in line with the policy of small profit and quick turnover, expanding the market, with reasonable prices and sincere service to provide quality products for various industries.
• Our team of professionals is dedicated to providing the best solutions for your garden lighting needs.
• Since its establishment, our company has been diligent and diligent in starting a business. At present, we have become a very specialized manufacturer of High Power Explosion Proof Garden Light. We firmly believe in the people-oriented development belief, actively develop towards the direction of intelligent manufacturing, and also absorb and train a group of professional talents, laying a solid foundation for future development.

Introducing the High Power Explosion Proof Garden Light - the most advanced lighting solution available in the market. As a leading manufacturer in China, we understand the needs of our global customers for high-quality products that offer superior performance and reliability.

Our High Power Explosion Proof Garden Light is designed to provide the perfect lighting solution for gardens, parks, public areas, and commercial properties. It is built with state-of-the-art technology and engineering standards that make it durable, energy-efficient, and resistant to extreme weather conditions.

With a power rating of XX watts, the High Power Explosion Proof Garden Light produces bright and clear light that illuminates any area with ease. Its high-quality LED bulbs are designed to last for thousands of hours, making it a cost-effective and environmentally friendly lighting solution.

The explosion-proof design of the High Power Explosion Proof Garden Light ensures that it can withstand any hazardous conditions and is safe for use in areas where there may be potentially explosive gases present. Its shock and vibration-resistance ability make it suitable for use in high-traffic areas where it is prone to damage from external factors.

The High Power Explosion Proof Garden Light has a sleek and modern design that integrates well with any outdoor setting. Its robust construction and durable materials make it ideal for use in harsh environments such as coastal areas, industrial estates, and public spaces.

One of the key advantages of our High Power Explosion Proof Garden Light is its energy efficiency. Its LED bulbs require minimal power consumption, which translates to lower electricity bills and reduced carbon footprint. This makes it an ideal choice for environmentally conscious businesses and individuals.

The High Power Explosion Proof Garden Light is easy to install and requires minimal maintenance. Its weather-resistant seals and anticorrosive coating ensure that it can withstand harsh weather and remain functional for years to come.

In conclusion, our High Power Explosion Proof Garden Light is a one-of-a-kind lighting solution that is designed to meet the needs of the modern world. Its superior performance, environmental sustainability, and high-quality engineering make it the perfect choice for businesses and individuals looking for advanced lighting solutions. Contact us today to order your High Power Explosion Proof Garden Light and take advantage of the benefits it offers!
