Low Voltage Alloy Garden Light

1. The lamp post is made of Q235 steel with a thickness of δ=4mm or more. The suppliers are well-known steel mills such as Baosteel and Magang.
2. The lamp post and bracket are hot-dip galvanized both inside and outside, with a galvanized layer thickness of not less than 85μm. The anti-corrosion lifespan is more than 30 years. The surface is treated with DuPont metal paint or spray, with a thickness of not less than 100μm. The number of modified parts due to straightening or other factors should not exceed 2, and the area for modification should not exceed 5% of the pole surface area.
3. The steel pole should be well welded. For tapered poles with a length of 8 meters or less, there should be no transverse welds, and the longitudinal welds should be symmetrical and without incomplete penetration. Under the condition of horizontal placement and no load, the straightness deviation of the pole body should be less than 3‰.
4. For flange-type lamp posts, the allowable deviation in pole length is ±0.5% of the pole length, the allowable deviation in cross-sectional dimensions of the pole body is ±0.5%, the allowable deviation in wiring hand hole size is ±5mm, the allowable deviation in the tilt angle of one-piece cantilever lamp poles is ±1°, and after the lamp arm (bracket) is connected and fixed to the lamp post, the deviation between the center verticality and the verticality of the lamp post should not exceed 3°.
5. The inspection door frame of the lamp post should have reinforcement measures to ensure that its mechanical strength is not lower than the strength when the door is closed.
6. The upper end of the inspection door of the lamp post is equipped with an anti-theft triangular stainless steel screw with a diameter of Φ10mm, and the lower end is hinged. The inner wall of the inspection door of the lamp post is welded with PE protection wire terminal.
7. The fastening screws and nuts of the lamp post and bracket are made of stainless steel.
8. The cable junction box is installed inside the bottom lamp holder crossbar, equipped with RT-14 fuse, 250W equipped with 6A fuse, 150W equipped with 4A fuse, 400W equipped with 10A fuse. The junction box is made of PTFE material.
9. The welding reinforcement ribs are required at the connection between the lamp post and the flange, with a thickness of not less than 8mm and a minimum of 4 reinforcement ribs.
10. The overhead line of the lamp post should use aviation waxed line with a rated voltage of not less than 500V. The minimum allowable cross-sectional area of the line core for power less than 400W should be 1.5mm², and the minimum allowable cross-sectional area of the line core for power from 400W to 1000W should be 2.5mm².
11. The overall wind resistance of the lamp post is above 30 m/s, and the seismic grade is above 8.
12. The lamp model drawing is for reference only. The specific dimensions, colors, processes, etc. should be based on actual survey or owner’s requirements.

Why choose us?

• Our focus is on providing the best garden lighting solutions that are both energy efficient and aesthetically pleasing.
• We aim at market demand and our own reality, and are committed to establishing integrity first, quality is life, and service is the soul.
• Our products are backed by comprehensive after-sales support to ensure customer satisfaction.
• We keep a close eye on the pulse of market development and the potential needs of users, and strive to provide the best Low Voltage Alloy Garden Light to the majority of users in the shortest possible time.
• Our garden lamps and lights are eco-friendly and contribute to reducing carbon footprints.
• With a mission of 'Commitment to Excellence', our R & D team, with many years of experience in the field of Low Voltage Alloy Garden Light, is constantly dedicated to improving the quality, performance and range of applications according to needs of customers.
• We only use high-quality materials to manufacture our garden lamps and lights.
• For our company, the service quality of customer relationship is as important as the technical quality of products. Therefore, customers are confident in our Low Voltage Alloy Garden Light.
• As a supplier and manufacturer, we offer competitive prices for our products.
• Green, smart, we are pursuing the goal, we will provide you with a reasonable design plan, technical and economic indicators for you to tailor a high standard Low Voltage Alloy Garden Light.

Introducing the Newest Low Voltage Alloy Garden Light, Perfect for Your Outdoor Needs!

If you're looking for a reliable and efficient outdoor lighting solution, look no further than our Low Voltage Alloy Garden Light. Designed for easy installation and long-lasting performance, this lighting system is perfect for your garden, lawn, driveway, and other outdoor areas.

Here are some of the key features of our low voltage garden light which will surely grab your attention:

1. Low Voltage Operation

The Low Voltage Alloy Garden Light operates on a low voltage of 12V, ensuring safe and energy-efficient performance. This means that you won't have to worry about high electricity bills or any other electrical problems like power surges and other issues that come with high voltage systems.

2. Durable Construction

Made from high-quality materials such as aluminum alloy and tempered glass, the Low Voltage Alloy Garden Light is durable and built to last. The housing is designed to resist corrosion, rust, and other outdoor elements, making it ideal for outdoor applications.

3. Great Aesthetic Appeal

The Low Voltage Alloy Garden Light is designed to blend seamlessly into your outdoor space with its simple yet modern design. The light emits a soft and warm glow that adds a relaxing and inviting ambiance to any outdoor setting. The low profile of the fixture also allows it to blend in with the surroundings, making it almost invisible during the day.

4. Easy Installation

Our Low Voltage Alloy Garden Light comes with a simple and easy installation process that doesn't require any special tools or skills. It can be mounted on a wooden or concrete surface with ease, and the low voltage transformer can be located remotely, away from the fixture itself, ensuring easy maintenance and constant operation.

5. Cost-Effective Solution

Compared to other types of outdoor lighting, the Low Voltage Alloy Garden Light is a cost-effective solution that doesn't require expensive wiring, installation, or maintenance fees. It is also highly energy-efficient and eco-friendly, which can save you a considerable amount of money in the long run while reducing your carbon footprint.

6. Versatile and Customizable

Our Low Voltage Alloy Garden Light is available in different sizes and styles, making it a versatile and customizable solution for any outdoor space. You can choose from various color temperatures, beam angles, and wattages to find the perfect combination that suits your needs and preferences.

Whether you're looking to illuminate your driveway, garden, lawn, or patio area, our Low Voltage Alloy Garden Light is the perfect solution for your outdoor lighting needs. Its low voltage operation, durable construction, great aesthetic appeal, easy installation, cost-effectiveness, and versatility make it the best choice for homeowners, landscapers, and commercial property owners alike.

Order now and bring a new level of ambiance and functionality to your outdoor space with our Low Voltage Alloy Garden Light!
