Aluminum Housing LED Garden Light

1. The lamp post is made of Q235 steel with a thickness of δ=4mm or more. The suppliers are well-known steel mills such as Baosteel and Magang.
2. The lamp post and bracket are hot-dip galvanized both inside and outside, with a galvanized layer thickness of not less than 85μm. The anti-corrosion lifespan is more than 30 years. The surface is treated with DuPont metal paint or spray, with a thickness of not less than 100μm. The number of modified parts due to straightening or other factors should not exceed 2, and the area for modification should not exceed 5% of the pole surface area.
3. The steel pole should be well welded. For tapered poles with a length of 8 meters or less, there should be no transverse welds, and the longitudinal welds should be symmetrical and without incomplete penetration. Under the condition of horizontal placement and no load, the straightness deviation of the pole body should be less than 3‰.
4. For flange-type lamp posts, the allowable deviation in pole length is ±0.5% of the pole length, the allowable deviation in cross-sectional dimensions of the pole body is ±0.5%, the allowable deviation in wiring hand hole size is ±5mm, the allowable deviation in the tilt angle of one-piece cantilever lamp poles is ±1°, and after the lamp arm (bracket) is connected and fixed to the lamp post, the deviation between the center verticality and the verticality of the lamp post should not exceed 3°.
5. The inspection door frame of the lamp post should have reinforcement measures to ensure that its mechanical strength is not lower than the strength when the door is closed.
6. The upper end of the inspection door of the lamp post is equipped with an anti-theft triangular stainless steel screw with a diameter of Φ10mm, and the lower end is hinged. The inner wall of the inspection door of the lamp post is welded with PE protection wire terminal.
7. The fastening screws and nuts of the lamp post and bracket are made of stainless steel.
8. The cable junction box is installed inside the bottom lamp holder crossbar, equipped with RT-14 fuse, 250W equipped with 6A fuse, 150W equipped with 4A fuse, 400W equipped with 10A fuse. The junction box is made of PTFE material.
9. The welding reinforcement ribs are required at the connection between the lamp post and the flange, with a thickness of not less than 8mm and a minimum of 4 reinforcement ribs.
10. The overhead line of the lamp post should use aviation waxed line with a rated voltage of not less than 500V. The minimum allowable cross-sectional area of the line core for power less than 400W should be 1.5mm², and the minimum allowable cross-sectional area of the line core for power from 400W to 1000W should be 2.5mm².
11. The overall wind resistance of the lamp post is above 30 m/s, and the seismic grade is above 8.
12. The lamp model drawing is for reference only. The specific dimensions, colors, processes, etc. should be based on actual survey or owner’s requirements.

Why choose us?

• Our team of professionals is dedicated to providing the best solutions for your garden lighting needs.
• The company has a high-level Aluminum Housing Led Garden Light performance testing center, and the products have undergone precision casting, hot forging and other processes.
• We take pride in our attention to detail when it comes to manufacturing garden lamps and lights.
• Our company adheres to the concept of 'technological innovation, pursuit of excellence, win-win cooperation, and sustainable operation', and takes 'customer first' and 'service satisfaction' as the eternal theme of the company. We warmly welcome new and old customers to inquire and patronize.
• Our manufacturing process is transparent, allowing customers to track their orders and deliveries.
• Our internal management process was further optimized, and the total cost of operation was continuously compressed and controlled.
• We have a team of dedicated designers who can create custom-made garden lamps and lights to match your specific needs.
• The unified, standardized and specialized production model is a powerful driving force for the rapid development of our company.
• We believe that our products and services are the best value for money in the industry.
• Our company will, as always, be demand-oriented, research and development as the driving force, and quality as the core.

Introduction:

Are you looking for a high-quality, energy-efficient garden light that can illuminate your outdoor space while adding a touch of elegance to your landscape? If so, then you are in the right place! The Aluminum Housing Led Garden Light is the perfect solution for all your outdoor lighting needs. Our product is designed to provide a long-lasting and reliable lighting solution that is both energy-efficient and visually appealing.

Description:

Our Aluminum Housing Led Garden Light is made from premium-quality materials that are designed to withstand harsh weather conditions, including wind, rain, and heat. The housing is made from high-quality aluminum, which provides excellent durability and a sleek, modern appearance. The light features advanced LED technology, which provides bright and warm lighting that is ideal for highlighting plants, pathways, and other garden features.

Features:

- High-quality aluminum housing: Our garden light is designed to provide a sleek and modern appearance that will complement any outdoor décor.

- Energy-saving LED technology: Our LED lights are designed to provide bright and warm lighting while consuming less energy than traditional lighting options.

- Durable and weather-resistant: Our garden light is made from high-quality materials that are designed to withstand harsh weather conditions, including wind, rain, and heat.

- Easy to install: Our garden light is easy to install, thanks to its simple and intuitive design.

- Versatile: Our garden light is suitable for a wide range of outdoor applications, including garden lighting, pathway lighting, and security lighting.

Benefits:

- Long-lasting: Our garden light is designed to provide a long-lasting and reliable lighting solution that is both energy-efficient and visually appealing.

- Cost-effective: Our LED lights are designed to provide bright and warm lighting while consuming less energy than traditional lighting options, which can save you money on your energy bills.

- Easy to install: Our garden light is easy to install, which means you can have your outdoor lighting solution up and running in no time.

- Versatile: Our garden light is suitable for a wide range of outdoor applications, which means you can use it to illuminate your garden, pathway, or other outdoor features.

- Environmentally-friendly: Our LED lights are designed to be environmentally-friendly, thanks to their energy-efficient design and low carbon footprint.

Conclusion:

The Aluminum Housing Led Garden Light is the perfect solution for anyone looking for a reliable and cost-effective outdoor lighting solution. Our product is designed to provide long-lasting and energy-efficient lighting that is suitable for a wide range of outdoor applications. So why wait? Contact us today to learn more about our Aluminum Housing Led Garden Light and start enjoying bright and warm lighting in your outdoor space!
