Explosion Proof Waterproof Garden Light

1. The lamp post is made of Q235 steel with a thickness of δ=4mm or more. The suppliers are well-known steel mills such as Baosteel and Magang.
2. The lamp post and bracket are hot-dip galvanized both inside and outside, with a galvanized layer thickness of not less than 85μm. The anti-corrosion lifespan is more than 30 years. The surface is treated with DuPont metal paint or spray, with a thickness of not less than 100μm. The number of modified parts due to straightening or other factors should not exceed 2, and the area for modification should not exceed 5% of the pole surface area.
3. The steel pole should be well welded. For tapered poles with a length of 8 meters or less, there should be no transverse welds, and the longitudinal welds should be symmetrical and without incomplete penetration. Under the condition of horizontal placement and no load, the straightness deviation of the pole body should be less than 3‰.
4. For flange-type lamp posts, the allowable deviation in pole length is ±0.5% of the pole length, the allowable deviation in cross-sectional dimensions of the pole body is ±0.5%, the allowable deviation in wiring hand hole size is ±5mm, the allowable deviation in the tilt angle of one-piece cantilever lamp poles is ±1°, and after the lamp arm (bracket) is connected and fixed to the lamp post, the deviation between the center verticality and the verticality of the lamp post should not exceed 3°.
5. The inspection door frame of the lamp post should have reinforcement measures to ensure that its mechanical strength is not lower than the strength when the door is closed.
6. The upper end of the inspection door of the lamp post is equipped with an anti-theft triangular stainless steel screw with a diameter of Φ10mm, and the lower end is hinged. The inner wall of the inspection door of the lamp post is welded with PE protection wire terminal.
7. The fastening screws and nuts of the lamp post and bracket are made of stainless steel.
8. The cable junction box is installed inside the bottom lamp holder crossbar, equipped with RT-14 fuse, 250W equipped with 6A fuse, 150W equipped with 4A fuse, 400W equipped with 10A fuse. The junction box is made of PTFE material.
9. The welding reinforcement ribs are required at the connection between the lamp post and the flange, with a thickness of not less than 8mm and a minimum of 4 reinforcement ribs.
10. The overhead line of the lamp post should use aviation waxed line with a rated voltage of not less than 500V. The minimum allowable cross-sectional area of the line core for power less than 400W should be 1.5mm², and the minimum allowable cross-sectional area of the line core for power from 400W to 1000W should be 2.5mm².
11. The overall wind resistance of the lamp post is above 30 m/s, and the seismic grade is above 8.
12. The lamp model drawing is for reference only. The specific dimensions, colors, processes, etc. should be based on actual survey or owner’s requirements.

Why choose us?

• We use the latest technology and techniques to manufacture our garden lamps and lights.
• Our team is working hard to optimize our own processes to improve development efficiency and add more humanized features to our Explosion Proof Waterproof Garden Light.
• We combine style and functionality to deliver the best garden lighting solutions to our customers.
• Our company reduces the cost of production, but also stable control of product quality, is the majority of consumers' ideal partner.
• We have a team of dedicated designers who can create custom-made garden lamps and lights to match your specific needs.
• We are mutually beneficial and harmonious with society, and contribute to economic development and social harmony.
• Our manufacturing facility adheres to strict safety standards to ensure the wellbeing of our workers and customers.
• We have been committed to becoming an excellent Explosion Proof Waterproof Garden Light supplier, providing customers with high-quality products, services and solutions.
• Our garden lamps and lights are designed to have a long lifespan, reducing the need for frequent replacements.
• We are adhering to the business philosophy of 'integrity-based, sustainable operation', international quality and professional services have enabled us to grow rapidly in the field of Explosion Proof Waterproof Garden Light.

Introduction

As a manufacturer located in China, we are proud to introduce our latest product – the Explosion Proof Waterproof Garden Light. This product is designed to meet the needs and requirements of merchants in countries outside of China who are looking for a high-quality, reliable, and durable garden light that can withstand harsh weather conditions and provide efficient illumination to their gardens.

In this product introduction, we will outline the key features and benefits of our Explosion Proof Waterproof Garden Light and explain how it can help merchants attract and retain customers.

Key Features

The Explosion Proof Waterproof Garden Light boasts of the following key features:

1. Explosion-proof Rating

Our garden light has been tested and certified to have an explosion-proof rating of Exd II CT6, which means it can effectively prevent the occurrence of explosions by preventing electric sparks from contacting explosive gas and dust.

2. Waterproof Rating

Our garden light has an IP65 waterproof rating, which means it is fully protected against dust and can withstand low-pressure water jets from any direction. This makes our garden light suitable for use in outdoor spaces such as gardens, parks, pathways, and courtyards.

3. Energy-Saving Technology

Our garden light features energy-saving technology that helps to maximize its lifespan and minimize its power consumption. The LED chips, for instance, have a service life of up to 50,000 hours, which means they can last for more than five years with regular use.

4. High-Quality Materials

Our garden light is made of high-quality materials, including aluminum and tempered glass, which make it durable and resistant to wear and tear. The tempered glass also helps to ensure that the light is evenly distributed, providing sufficient illumination to the garden.

5. Easy Maintenance

Our garden light is designed for easy maintenance, which means merchants can easily replace any faulty components without having to replace the entire light. The light is also easy to clean and requires minimal upkeep.

Benefits

Merchants who invest in our Explosion Proof Waterproof Garden Light stand to enjoy the following benefits:

1. Enhanced Safety

Our garden light's explosion-proof rating enhances the safety of outdoor environments by preventing explosions from occurring. This ensures that customers can enjoy their outdoor spaces with peace of mind.

2. Energy Savings

Our garden light's energy-saving technology helps to reduce power consumption, which can lead to significant long-term savings on energy bills.

3. Long Lifespan

Our garden light's high-quality materials and energy-saving technology help to maximize its lifespan, which minimizes the need for frequent replacements and reduces long-term maintenance costs.

4. Durable and Reliable

Our garden light's high-quality materials make it durable and resistant to wear and tear, ensuring that it can withstand harsh weather conditions and provide reliable illumination to the garden.

Conclusion

In summary, the Explosion Proof Waterproof Garden Light is an ideal product for merchants looking for a high-quality, reliable, and durable garden light that can withstand harsh weather conditions and provide efficient illumination to their gardens. With its key features such as an explosion-proof rating, waterproof rating, energy-saving technology, high-quality materials, and easy maintenance, this product offers a range of benefits that can help merchants attract and retain customers. Invest in our Explosion Proof Waterproof Garden Light today and enjoy enhanced safety, energy savings, long lifespan, and durability.
