Dust-Proof Aluminum Housing Garden Light

1. The lamp post is made of Q235 steel with a thickness of δ=4mm or more. The suppliers are well-known steel mills such as Baosteel and Magang.
2. The lamp post and bracket are hot-dip galvanized both inside and outside, with a galvanized layer thickness of not less than 85μm. The anti-corrosion lifespan is more than 30 years. The surface is treated with DuPont metal paint or spray, with a thickness of not less than 100μm. The number of modified parts due to straightening or other factors should not exceed 2, and the area for modification should not exceed 5% of the pole surface area.
3. The steel pole should be well welded. For tapered poles with a length of 8 meters or less, there should be no transverse welds, and the longitudinal welds should be symmetrical and without incomplete penetration. Under the condition of horizontal placement and no load, the straightness deviation of the pole body should be less than 3‰.
4. For flange-type lamp posts, the allowable deviation in pole length is ±0.5% of the pole length, the allowable deviation in cross-sectional dimensions of the pole body is ±0.5%, the allowable deviation in wiring hand hole size is ±5mm, the allowable deviation in the tilt angle of one-piece cantilever lamp poles is ±1°, and after the lamp arm (bracket) is connected and fixed to the lamp post, the deviation between the center verticality and the verticality of the lamp post should not exceed 3°.
5. The inspection door frame of the lamp post should have reinforcement measures to ensure that its mechanical strength is not lower than the strength when the door is closed.
6. The upper end of the inspection door of the lamp post is equipped with an anti-theft triangular stainless steel screw with a diameter of Φ10mm, and the lower end is hinged. The inner wall of the inspection door of the lamp post is welded with PE protection wire terminal.
7. The fastening screws and nuts of the lamp post and bracket are made of stainless steel.
8. The cable junction box is installed inside the bottom lamp holder crossbar, equipped with RT-14 fuse, 250W equipped with 6A fuse, 150W equipped with 4A fuse, 400W equipped with 10A fuse. The junction box is made of PTFE material.
9. The welding reinforcement ribs are required at the connection between the lamp post and the flange, with a thickness of not less than 8mm and a minimum of 4 reinforcement ribs.
10. The overhead line of the lamp post should use aviation waxed line with a rated voltage of not less than 500V. The minimum allowable cross-sectional area of the line core for power less than 400W should be 1.5mm², and the minimum allowable cross-sectional area of the line core for power from 400W to 1000W should be 2.5mm².
11. The overall wind resistance of the lamp post is above 30 m/s, and the seismic grade is above 8.
12. The lamp model drawing is for reference only. The specific dimensions, colors, processes, etc. should be based on actual survey or owner’s requirements.

Why choose us?

• As a supplier and manufacturer, we offer competitive prices for our products.
• We take the production of high quality products as our mission, customers and our mutual success as our objective, and striving to build a world-class brand.
• We have a track record of delivering high-quality products and services to our customers.
• Our company is a professional supplier of Dust-Proof Aluminum Housing Garden Light, established in XXXX year. After China joined the WTO, the global market opened to us. At the same time, with the process of globalization, our goal has also expanded: to bring high-quality products to consumers all over the world.
• Our garden lamps and lights are designed to be low maintenance, saving customers time and money.
• The company takes the people-oriented concept to the extreme and improves customer satisfaction with our products.
• Our garden lamps and lights are easy to maintain and operate, requiring minimal attention.
• At present, the company has a number of advanced production technologies, strong technical force, strong production capacity, and modern production bases, which effectively guarantee the company's product quality and stable delivery speed. We adhere to the concept of excellence and pursuit of excellence, and welcome friends from all walks of life to visit the factory and discuss cooperation.
• Our garden lamps and lights are aesthetically pleasing and blend seamlessly with the natural surroundings.
• The spirit of our professional conduct connotes, loyalty, diligence, efficiency and harmony.

The Dust-Proof Aluminum Housing Garden Light is an outstanding outdoor lighting fixture that is perfect for your business. As a manufacturer located in China, we have been in the industry for many years, creating high-quality and durable products for our clients. Our Dust-Proof Aluminum Housing Garden Light is just one of the many products that we offer, and it is an excellent choice for anyone in the market for a lighting solution that is both durable and attractive.

Firstly, one of the key features of our Dust-Proof Aluminum Housing Garden Light is its unique design. It is made of high-quality aluminum material that is not only durable but also very stylish. Its sleek and streamlined design makes it a perfect addition to any outdoor environment, from parks and gardens to walkways, driveways, and homes. The smooth texture of the housing material will amaze your customers and leave a long-lasting impression.

Another great aspect of our product is its superior waterproof and dustproof capabilities. The light is designed to withstand harsh weather conditions such as extreme heat, cold, high humidity, and heavy rain. You can use it in any outdoor environment without worrying about water damage or dust accumulation. This feature not only assures merchants that this product is a reliable choice for outdoor illumination, but it can also be used in coastal or industrial areas, which makes it a highly versatile product for merchants to consider selling to their customers.

Our Dust-Proof Aluminum Housing Garden Light also features high-quality LED lights that offer bright and consistent lighting. The LED lights are energy-efficient, making them the perfect choice for environmentally conscious customers and those looking to cut down on electricity costs. Furthermore, the color temperature of the LED lights is very neutral and won’t distort the color of any surrounding elements, making it a perfect lighting option for outdoor photographs and events.

In addition to its functionality and design, our Dust-Proof Aluminum Housing Garden Light is also very easy to install. The light comes with all the necessary fittings and instructions, making it a perfect do-it-yourself project. This feature will surely attract merchants looking to offer their customers an easy-to-install product that does not require additional professional expenses.

Lastly, our Dust-Proof Aluminum Housing Garden Light comes with a warranty that covers any damage or defects in manufacturing for a particular duration. This guarantees merchants confidence in marketing the product to customers, assuring them of its durability.

In conclusion, the Dust-Proof Aluminum Housing Garden Light offers a wide range of benefits that make it an excellent choice for anyone in the market for an outdoor lighting solution. Its unique design, waterproof and dustproof capabilities, high-quality LED lights, easy installation, and warranty offers assurance to merchants looking for a cost-efficient but high-quality product to sell. Attract merchants with a showcase of these features and secure a lucrative partnership with your business.
