Aluminum Galvanized Garden Light

1. The lamp post is made of Q235 steel with a thickness of δ=4mm or more. The suppliers are well-known steel mills such as Baosteel and Magang.
2. The lamp post and bracket are hot-dip galvanized both inside and outside, with a galvanized layer thickness of not less than 85μm. The anti-corrosion lifespan is more than 30 years. The surface is treated with DuPont metal paint or spray, with a thickness of not less than 100μm. The number of modified parts due to straightening or other factors should not exceed 2, and the area for modification should not exceed 5% of the pole surface area.
3. The steel pole should be well welded. For tapered poles with a length of 8 meters or less, there should be no transverse welds, and the longitudinal welds should be symmetrical and without incomplete penetration. Under the condition of horizontal placement and no load, the straightness deviation of the pole body should be less than 3‰.
4. For flange-type lamp posts, the allowable deviation in pole length is ±0.5% of the pole length, the allowable deviation in cross-sectional dimensions of the pole body is ±0.5%, the allowable deviation in wiring hand hole size is ±5mm, the allowable deviation in the tilt angle of one-piece cantilever lamp poles is ±1°, and after the lamp arm (bracket) is connected and fixed to the lamp post, the deviation between the center verticality and the verticality of the lamp post should not exceed 3°.
5. The inspection door frame of the lamp post should have reinforcement measures to ensure that its mechanical strength is not lower than the strength when the door is closed.
6. The upper end of the inspection door of the lamp post is equipped with an anti-theft triangular stainless steel screw with a diameter of Φ10mm, and the lower end is hinged. The inner wall of the inspection door of the lamp post is welded with PE protection wire terminal.
7. The fastening screws and nuts of the lamp post and bracket are made of stainless steel.
8. The cable junction box is installed inside the bottom lamp holder crossbar, equipped with RT-14 fuse, 250W equipped with 6A fuse, 150W equipped with 4A fuse, 400W equipped with 10A fuse. The junction box is made of PTFE material.
9. The welding reinforcement ribs are required at the connection between the lamp post and the flange, with a thickness of not less than 8mm and a minimum of 4 reinforcement ribs.
10. The overhead line of the lamp post should use aviation waxed line with a rated voltage of not less than 500V. The minimum allowable cross-sectional area of the line core for power less than 400W should be 1.5mm², and the minimum allowable cross-sectional area of the line core for power from 400W to 1000W should be 2.5mm².
11. The overall wind resistance of the lamp post is above 30 m/s, and the seismic grade is above 8.
12. The lamp model drawing is for reference only. The specific dimensions, colors, processes, etc. should be based on actual survey or owner’s requirements.

Why choose us?

• We offer a fast and reliable delivery service for our garden lamps and lights.
• We take "striving to innovate for the realization of customer goals" as our corporate mission, and continue to devote ourselves to product development and innovation, and help partners succeed!
• We have a team of experts who can provide guidance on the selection and placement of garden lamps and lights.
• Our company is a comprehensive Aluminum Galvanized Garden Light enterprise. With many years of management experience, we have introduced various advanced equipment, updated management methods, established a perfect quality control mechanism and after-sales service mechanism, and deeply expanded the value of products to serve more enterprises.
• We offer different types of garden lamps and lights, including solar-powered, LED, and traditional lamps.
• "Efforts, let us win-win" is the company's eternal cooperation concept; "customer-centric, strive to make customers satisfied" is the goal of the company's unremitting pursuit.
• We have a wide range of garden lamps and lights to choose from, catering to different needs and preferences.
• The success and development depend on the support and trust of customers.
• We use the latest technology and techniques to manufacture our garden lamps and lights.
• Our future work will focus on improving the quality of our Aluminum Galvanized Garden Light, perfecting the standard system, and taking the route of internationalization and industrialization.

Introducing the Aluminum Galvanized Garden Light: A High-Quality, Energy-Efficient Solution for Outdoor Lighting Needs

If you are looking for an affordable yet high-quality outdoor lighting solution, look no further than the Aluminum Galvanized Garden Light. As a leading manufacturer of outdoor lighting products in China, we are pleased to offer our customers an innovative, energy-efficient, and stylish lighting option that is perfect for a wide range of applications.

At the heart of the Aluminum Galvanized Garden Light is our cutting-edge LED technology, which delivers bright and radiant light without consuming a lot of energy. This means not only will you enjoy beautifully illuminated outdoor spaces, but you will also save money on your energy bills over time.

Choose from a variety of sizes and styles to fit your exact needs and preferences. Whether you're looking for a traditional or modern design, our Aluminum Galvanized Garden Lights offer an array of options that are sure to please. Plus, with our durable galvanized aluminum construction, your lights will withstand even the harshest outdoor conditions for years to come.

Other benefits of choosing our Aluminum Galvanized Garden Lights include:

Efficient Use of Energy - The LED technology in our lights maximizes efficiency by producing bright light with minimal energy.

Long-Lasting - Our galvanized aluminum construction ensures your lights will withstand weathering and outdoor conditions.

Stylish Design - Our Aluminum Galvanized Garden Lights come in a variety of designs to fit your outdoor aesthetic.

Easy Installation - Our lights are easy to install and come with everything you need to get started right away.

Flexible Use - Our lights can be used for a range of outdoor applications, including pathways, gardens, patios, and more.

Conclusion

Overall, the Aluminum Galvanized Garden Light offers a high-quality, energy-efficient, and stylish solution for all your outdoor lighting needs. With our durable construction, efficient LED technology, and variety of styles and sizes, our lights are a smart investment for any homeowner or business owner looking to improve the appearance, functionality, and safety of their outdoor spaces. Contact us today to learn more about our product offerings and to place your order.
